| Our Part # |
Item # |
Description |
Price |
Quantity |
|
| 7060240 |
1
|
Spindle Housing #6595 Qty Needed 1 |
$719.04 |
|
|
| 7060035 |
2
|
Spindle #6596-3 Qty Needed 1 |
$184.74 |
|
|
| 7060036 |
3
|
Spacer Gear # 6597 Qty Needed 1 |
$67.51 |
|
|
| 7060188 |
4
|
Cover Gear # 6598-2 Qty Needed 1 |
$54.51 |
|
|
| 7060232 |
5
|
Spindle Spacer #6599 Qty Needed 1 |
$7.29 |
|
|
| 7060038 |
6
|
Spindle Shim #A-6600-4 Qty Needed 2 |
$19.52 |
|
|
| 7060039 |
7
|
Clamp #6601 Qty Needed 1 |
$12.18 |
|
|
| 7060220 |
8
|
Adjustment Knob #6602-2 Qty Needed 1 |
$41.09 |
|
|
| 7060230 |
9
|
Adjusting Bushing #6603-2 Qty Needed 1 |
$139.42 |
|
|
| 7060244 |
10
|
Pressure Foot Bar 6604-4 Qty Needed 1 |
$121.80 |
|
|
| 7060242 |
11
|
Pressure Foot #6605 (Qty Needed 1) |
$68.97 |
|
|
| 7060228 |
12
|
Block Bushing # 6606-3 Qty Needed 1 |
$54.73 |
|
|
| 7060250 |
13
|
Pressure Foot Cover #6607 Qty Needed 1 |
$13.50 |
|
|
| 7060248 |
14
|
Pointer #6608 Qty Needed 1 |
$7.48 |
|
|
| 7060040 |
15
|
Teflon Plunger #6609 Qty Needed 1 |
$6.01 |
|
|
| 7060003 |
17
|
Jam Nut 1/4x20 Thin #H-5240-4 Qty Needed 1 |
$0.75 |
|
|
| 7060120 |
18
|
Dowel Pin 1/8x3/8 #H-5246-203 (Qty Needed 2) |
$0.67 |
|
|
| 7060002 |
19
|
Woodruff Key 1/2x1/8 #H-6121-804 Qty Needed 1 |
$0.75 |
|
|
| 7060194 |
20
|
Hex Jam Nut 1/4 x 20 Heavy #H-6529-4 Qty Needed 1 |
$0.67 |
|
|
| 7060252 |
21
|
Button Head Screw #8-32x1/4 #H-6910-83202 Qty Needed 2 |
$0.75 |
|
|
| 7060246 |
22
|
Cap Screw #10-24x3/8 #H-6910-102403 Qty Needed 6 |
$0.75 |
|
|
| 7060254 |
23
|
Socket Head Cap Screw 1/4-20 x 3/4 #H-6918-406 Qty Needed 2 |
$0.75 |
|
|
| 7060234 |
24
|
Cap Screw 3/8-16x1-1/2 #H-6918-612 Qty Needed 1 |
$0.75 |
|
|
| 7060124 |
25
|
Round Head Machine Screw #6-32x1/4 #H-6923-63204 Qty Needed 2 |
$0.67 |
|
|
| 7060196 |
26
|
Set Screw #10-24x1/4 #H-6938-102404 Qty Needed 1 |
$0.67 |
|
|
| 7060238 |
27
|
Nylock Screw 1/2-13x1/2 #H-6951-808 Qty Needed 2 |
$1.46 |
|
|
| 7060236 |
28
|
Lock Washer 3/8 Washer H-7327-12 Qty Needed 1 |
$0.75 |
|
|
| 7060129 |
29
|
Cover for Drift hole #K-85 Qty Needed 1 |
$62.45 |
|
|
| 7060135 |
30
|
Coil Spring #S-1255-1 Qty Needed 2 |
$4.66 |
|
|
| 7060143 |
31
|
Bronze Bushing #S-1719 Qty Needed 1 |
$8.50 |
|
|
| 7060189 |
32
|
Bushing Bronze #S-1720 Qty Needed 1 |
$1.46 |
|
|
| 7060144 |
33
|
Spindle Gear #S-1721 Qty Needed 1 |
$68.70 |
|
|
| 7060145 |
34
|
Helical Gear # S-1722 Replace in pairs with item 17 |
$90.96 |
|
|
| 7060146 |
35
|
Thrust Bearing #S-1723 Qty Needed 1 |
$42.69 |
|
|
| 7060147 |
36
|
Inner Spring #S-1724 -2 Qty Needed 1 |
$1.47 |
|
|
| 7060148 |
37
|
Outer Spring #S-1724-3 Qty Needed 1 |
$1.74 |
|
|
| 7060149 |
38
|
Grease Fitting #S-1725 (Qty Needed 2) |
$2.94 |
|
|
| 7060150 |
39
|
Thrust Bearing #S-1742 Qty Needed 1 |
$5.20 |
|
|
| 7060077M |
|
NEW CHALLENGE DRILL HEAD COMPLETE #A-6594-6 |
$1,020.53 |
|
|
